Each computing board consumes approximately 360-460 watts and is rated at 12 volts and 34.3 amps.
The total power consumption of the S9 is between 1078 and 1550 watts, depending on the power and ambient temperature.
The maximum power consumption at a temperature of 40 ° C is 1550 watts.
Powering the unit with a standard power adapter will result in approximately 1600 watts (533W per board) of power consumption.
Physical parameters of ant mining machine S9
1. Check all the connections and make sure they are connected properly. Make sure they are securely connected and in the correct alignment.
2. When powering up the machine, be sure to power on the control board before powering on the control board.
3. At 220V, the total current of S9 is about 8 amps and 9 amps at 110V. Most household power outlets only offer 10 amps. For your safety, if you are operating the S9 at home, power it through two outlets located on separate power cords. If you are not familiar with residential wiring, we recommend that you do not use this machine for home mining.
4. When setting up the device, leave a proper space between the power supply and the mining machine.
5. S9 uses the DHCP protocol to obtain an IP address. The default login username and password are both "root"
S9 computing power 13.5T, the current network computing power 6.39EH / s, 1E = 1024P, 1P = 1024T, 1T = 1024G, a s9 day generated bitcoin is [13.5 / (6.39 * 1024 * 1024)] * 180 ≈0.0036BTC.
Ant mining machine S9 digging bitcoin detailed tutoriala) After the mine machine is installed and the power is turned on, the mine machine automatically assigns an IP address. First, check the IP address of the mine machine. The following is a simple method.
1. Open the management address of the router in the browser (on the label attached to the manual or router), and find the IP address of the latest access device, that is, the IP of the newly accessed mining machine. There are many kinds of routers, and the principles are similar. Now take 360 ​​router as an example to explain, log in to the 360 ​​router management address http://luyou.360.cn, enter the management password.
After logging in, click on "Who is online":
According to the online time and device name of the connected network device, it can be determined which one is the mine machine just accessed, and the corresponding IP is the mining machine IP we are looking for.
2. Use 360 ​​to find the local IP address of the mining machine. Open 360 Security Guard, enter the function, enter "Traffic Firewall" in the search bar, press Enter.
In the "Traffic Firewall" window, click on "Anti-Small Network". After a while, the device connected to the network will appear. The IP of the unknown device is the IP address of the mining machine.
b) Check whether the IP and computer of the mining machine are in the same network segment, such as computer 192.168.1.1, mining machine 192.168.1.105, indicating that the two are in the same network segment; computer 192.168.1.1, mining machine 192.168.0.6 means that the two are not the same A network segment.
If the two are on the same network segment, directly perform the following steps.
If the two are not on the same network segment, complete the third step afterwards, and then perform the following steps.
1. Open the browser, enter the IP of the mining machine found above into the browser address bar, press Enter, the authentication window will appear. The default username and password are: root, log in after entering.
2. After logging in, find MinerConfiguraTIon/GeneralSetTIngs and set up three mine pools.
URL: Fill in the mining address. When the pool1 address is not connected, it will automatically connect to pool2.
Worker: Create a miner name in the format: username. Number or lowercase letters (username is the username you entered when registering with F2Pool).
Password: Miner password (can be set freely).
After setting up the three pools, click on “Save&Apply†in the lower right corner.
3. After the setup is completed, start running after about several tens of seconds. Go to “MinerStatus†to see the real-time status of the mine. After observing the normal indicators, you can wait for the receipt of the coins.
3) The mining machine and the computer are not in the same network segment, the mining machine can't enter the background, and it should be changed to our network segment, and then the second step. Take the existing network segment as 192.168.1.1 and the mining network segment 192.168.0.86 as an example.
1. Enter the router to change the same network segment as the mining machine.
2. After the router restarts, it enters the mine machine background 192.168.0.86. Change the mining machine to our previous network segment. After modification, click “Save&Apply†in the lower right corner.
3. Re-enter the router and change the temporary network segment back to the original network segment, so the IP of the mining machine becomes 192.168.1.68.
d) If you need to set other items, please look down. If you don't need to set it up, the fourth step will end.
1. Frequency setting:
2. Network settings:
